Multifunctional Thread Cutting Machine , Thread Rolling Machine 50HZ 60HZ

Brand Name:	Heling Machine
Model Number:	M16-400
MOQ:	1pcs
Price:	Welcome to Inquire
Payment Terms:	T/T
Supply Ability:	80+SET+PER month

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

10221508

Name:

Thread Cutting Machine

Voltage:

380V/440V/415V,50HZ/60HZ

Usage:

Efficient Automation Fully Automatic Continuous Operation, Integrating Multiple Processes Such As Straightening, Cutting, Forming, And Thread Rolling, Significantly Improving Production Efficiency And Reducing Labor Costs. Precision And Reliability Adoptin

Warranty:

1 Year

After-sales Service Provided:

Online Support,Video Technical Support

Core Components:

Bearing, Motor, Pump

Core Selling Points:

Easy To Operate, Long Service Life, High Productivity, Patented Product, Automatic, Multi-functional, High Precision

Package:

Wooden Case

Color:

Customizable

Packaging Details:

wooden box

Supply Ability:

80+SET+PER month

Highlight:

Multifunctional Thread Cutting Machine

Thread Cutting Machine 60HZ

Thread Rolling Machine 50HZ

Product Description

Precision Automatic Cutting & Thread Forming Machine – Consistent Thread Quality Guaranteed

Advanced automated solution integrating straightening, cutting, and thread forming processes for maximum efficiency and precision.

Key Features

Full-process automation: Integration of straightening, cutting, and thread forming with one-button operation, eliminating manual intervention and saving labor
High precision and stability: Precision transmission with forming error of ±0.05mm and strong product consistency
Multi-process integration: Complete all processing in one operation, reducing process connections with maximum output of 60 pieces per minute
Wide adaptability: Compatible with multiple materials including iron, steel, and stainless steel, supporting multi-specification and non-standard parts customization

Technical Specifications

Model	Manufacturable Diameter Range (mm)	Customizable Length Range (mm)	Weight (KG)	Capacity (PCS/min)
M6	4-6	70-200	1000-2000	40-65
M8	5-8	80-300	1700-2400	40-60
M10	6-10	130-500	2200-3200	25-60
M12	8-12	160-800	3000-8500	25-55
M14	10-14	200-800	3800-8600	25-55
M16	12-16	200-800	4200-7800	25-50
M20	16-20	400-800	9500-15000	25-45
M24	18-24	400-1000	10000-15000	20-40
M27	20-27	400-1000	10500-15000	15-35

Product Gallery

Multifunctional Thread Cutting Machine , Thread Rolling Machine 50HZ 60HZ 0

Multifunctional Thread Cutting Machine , Thread Rolling Machine 50HZ 60HZ 1

Multifunctional Thread Cutting Machine , Thread Rolling Machine 50HZ 60HZ 2

Key Advantages

Independently developed transmission technology ensures stable, durable equipment with low failure rate. Full automation saves labor while low energy consumption controls operational costs. Quick response to non-standard customization requirements with timely after-sales service, adapting to diverse international procurement needs.

Factory & Exhibition Showcase Multifunctional Thread Cutting Machine , Thread Rolling Machine 50HZ 60HZ 6
